Lovely light beam experiment

Lovely light beam experiment

Follow FizzicsEd 150 Science Experiments:

You will need:

A clear plastic bottle

Water

A flashlight

Aluminium foil

A dark Room

Copyright

Lovely light beam science experiment - materials needed
1 Lovely light beam science experiment - rolling water bottle in foil

Wrap the sides of the bottle in aluminium foil.

2 Lovely light beam science experiment - foil around water bottle cap

Fill the bottle with water and turn off the lights.

3 Lovely light beam science experiment - torch aimed at the bottom of the bottle

As you turn the bottle upside down, to pour the water out, shine the torch through the base of the bottle.

4 Lovely light beam science experiment - green laser light internal refraction within water stream

The lights shines through the water and creates a beam of light that pours from the mouth of the bottle. A stream.

5 A television screen showing a distance educator running science experiment with a bell jar, vacuum pump and a cup of water. There is an inset of a remote class on the screen and a video conference camera on top of the television.
Live remote classes with experienced distance educators

Discover >30 virtual workshops designed to engage students isolated at home.

  • Direct curriculum links
  • Up to 30 homes can connect together.
  • Live classes – students can question & answer our educators and participate in experiments using household materials
  • Simple connection via one-click connect
  • Based on 10 years of distance education experience & global best practice

Multi-award-winning distance classes available to keep up student enthusiasm & enrichment!

orange arrow Read more button

Why Does This Happen?

The light is internally bouncing within the water stream. Producing a nicely focused beam of light.
Light travels through optical cables in a similar fashion, bouncing through the cables to convey information between users. This process of light bouncing within a substance as it travels is known as Total Internal Reflection.

Variables to test

More on variables here

  • What happens when you remove the aluminium foil from the bottle?
  • Try using a laser pointer with adult supervision. Does this work better than the flashlight? Why? Try different laser types.
  • How far can the water fall and still show the trapped light effect?

Enjoy!
